Poly-Spectrum-8/V (for large animals)
Digital ECG System for Horses
- standard 12-lead ECG
- special ECG electrodes with 6-meter cable
- intelligent software with animal-specific algorithm
- ECG monitoring during surgery
Standard 12-lead ECG
Poly-Spectrum-8/V can record ECG in horses from the standard (I, II, III) and augmented (aVR, aVL, aVF) leads as well as from the horse-specific base-apex and Y leads. The recorded ECG data is displayed on the screen and can be printed out using any printer.
Special ECG Electrodes with 6-meter Cable
Poly-Spectrum-8/V is supplied with the reusable peripheral plate electrodes that feature 2-meter cable. The long cable assures mobility for a patient which makes a recording of ECG in large animals even more convenient. The plate electrodes are easy to apply and guarantee excellent signal quality.
Intelligent Software with Animal-Specific Algorithm
The supplied software ensures automatic QRS detection, calculation of all temporary parameters, and report generation. The specific algorithm adapted to the aspects of ECG in horses is applied here. For more accurate ECG analysis, animal weight should be specified. The software also features particularly created digital filters that ensure excellent noise suppression. ECG measurement and interpretation, as well as exam reports, are saved in a well-organized software database.
ECG Monitoring During Surgery
Poly-Spectrum-8/V can be used as an ECG monitor during surgery. It ensures sound notification for every detected QRS complex and shows the current heart rate in real time. This pocket-sized device can be placed in a bag together with a notebook and powered from it. This means that long-term ECG monitoring system is always at hand no matter where you perform surgery: at your clinic or at the patient’s location.The support of HL7 standard allows integrating all diagnostic Neurosoft systems into the information system of a healthcare facility.
The delivery set can differ from country to country. Request the actual delivery set for your country from your local representative.
|Poly-Spectrum-8/V electronic unit||1 pcs.|
|ECG cable, 2.0 m||1 pcs.|
|Reusable peripheral plate electrode for limb F9024 , F9024/RU10-SSC||4 pcs.|
|Rubber belt to fix the electrodes||2 pcs.|
|Rubber tape fixator||8 pcs.|
|Electrode fixation tape , 300 mm||4 pcs.|
|Electrode gel Unimax , 250 g||1 pcs.|
|Technical Manual «Poly-Spectrum-8/V»||1 pcs.|
|User manual «Poly-Spectrum.NET»||1 pcs.|
|Transportation bag||1 pcs.|
|License for the use of software "Poly-Spectrum.NET" with additional software module "Poly-Spectrum.NET/Veterinary"||1 pcs.|
