Miniature 12-Channel Digital ECG System with Measurement and Interpretation
- 12 high-quality standard ECG leads
- high-quality ECG recording under any conditions
- detection of pacemaker pulses
- automatic ECG measurement and interpretation
- automatic report generation
12 High-quality Standard ECG Leads
Poly-Spectrum-8/E is a pocket-sized ECG system. It ensures simultaneous ECG recording from 1 to 12 channels. Everything you need is to connect the system to your PC via a USB port.
High-Quality ECG Recording under Any Conditions
Poly-Spectrum-8/E digitizes ECG at a high sampling rate. The system together with a hardware module for compensation of patient cable capacitance caused by its vibrations and a set of powerful digital filters ensures high-quality ECG under any conditions.
Detection of Pacemaker Pulses
A built-in pacemaker pulse detector allows performing examinations of patients with implanted pacemakers and carrying out exercise tests and electrophysiology studies using transesophageal cardiac stimulation.
Automatic ECG Measurement and Interpretation
Poly-Spectrum-8/E includes Poly-Spectrum.NET/Analysis software (base delivery set) for ECG measurement and interpretation.
In ECG measurement and interpretation mode, a physician can see the selected QRS complex or the one averaged by the selected epoch. The software automatically sets the markers in the reference points of the QRS complex. The automatically generated report is shown in the same window. By clicking the QRS complex at any trace, a physician can zoom the trace for a detailed view, perform the necessary measurements and correct marker positions manually.
Automatic Report Generation
When the analysis is completed, the report is generated automatically. It includes data about QRS complexes for all leads, measurement tables, and result interpretation. A physician can make any changes to the report.
Support of HL7 and DICOM Standard Allows Integrating All Diagnostic Neurosoft Systems into the Information System of a Healthcare Facility
Nowadays all large medical centers and a range of small clinics are equipped with information systems intended to store and process their medical data. To make their workflow reliable and effective the software shall interface with such systems.
HL7 (Health Level 7) is the most commonly used interface engine for the exchange, integration, sharing and retrieval of electronic health information. Neurosoft software supports data exchange via HL7. Nevertheless, HL7 defines just a message format and general principles of data transfer while each specific information system can use its own messaging standards. The specialists of our company can easily set up the software to fit the needs of any clinic and thus provide the most effective integration via HL7.
Neurosoft software also supports DICOM network protocol. Using DICOM modality worklist the diagnostic software can interchange data with the information system of a clinic: obtain data regarding the required studies and transfer the results of performed studies to the information system of a clinic.The support of HL7 standard allows integrating all diagnostic Neurosoft systems into the information system of a healthcare facility.
The delivery set can differ from country to country. Request the actual delivery set for your country from your local representative.
|Poly-Spectrum-8/E electronic unit||1 pcs.|
|10-lead ECG cable with banana connector 3.1 m P.NR.S04325А||1 pcs.|
|Reusable limb clamp ECG electrode F9024SSC||4 pcs.|
|Reusable precordial suction chest ECG electrode F9009SSC , FIAB,Italy||6 pcs.|
|Unispray сonductive electrode spray||1 pcs.|
|Electrode gel Unimax , 250 g||1 pcs.|
|Technical Manual «Poly-Spectrum-8, 8/E»||1 pcs.|
|Warranty certificate||1 pcs.|
|User manual «Poly-Spectrum.NET»||1 pcs.|
|Annex to user manual «Exam Manager»||1 pcs.|
|Transportation bag||1 pcs.|
|Warranty certificate||1 pcs.|
|License for the use of software "Poly-Spectrum.NET" with additional software module "Poly-Spectrum.NET/Analysis"||1 pcs.|
