Cardiorespiratory Monitoring

Neuron-Spectrum-AM/CRM (type III sleep monitor)


  • cardiorespiratory monitor (Type III) expandable to a full-featured sleep diagnostic system (Type I or Type II)
  • detection and analysis of respiratory events, heart rate, SpO2, body position
  • software with automatic tools for PSG analysis
  • built-in memory for exam data storage
  • up to three days of continuous operation in the stand-alone mode
Cardiorespiratory Monitoring

Description

Cardiorespiratory monitor (Type III) expandable to a full-featured sleep diagnostic system (Type I or Type II)

Neuron-Spectrum-AM/CRM system can be used as Type III device for diagnostics of sleep disorders. Upon customer request, the system can be any time expanded to a full-featured sleep diagnostic system (Type I or Type II) that allows for a more detailed analysis of sleep-related disorders.

Detection and analysis of respiratory events, heart rate, SpO2 and body position

Neuron-Spectrum-AM/CRM is specially designed for cardiorespiratory monitoring at night and allows detecting and analyzing respiratory events, heart rate, and blood oxygen saturation during sleep. The electronic unit also features built-in body position sensors and a light sensor.

Sleep analysis is easy!

Thinking of a patient and a medical specialist, we strived to make the examination easy and comfortable for both of them.

The compact electronic unit is securely attached to the patient’s body using straps. Then the thermistor airflow sensor, thorax and respiratory effort sensors, ECG, and SpO2 sensors are connected to the unit.

Thanks to the intuitive display and controls, the device can be used by the patient without any assistance. The examination will be recorded to the built-in memory card for further interpretation by the specialist.

Automatic software tools for data analysis

The supplied software features tools for quick search, manual and automatic detection of snoring, respiratory events, desaturation, tachycardia, bradycardia, asystole, and other events. At the end of the examination, the software will generate the report according to the selected template.

Built-in memory for exam data storage

The recorder may have a built-in memory card of up to 32 GB (depending on customer requirements) where the data of several exams can be stored. By connecting the memory card to a computer, you can transfer the results of your exams to a database for viewing and analysis using the special software.

Up to three days of continuous operation in the stand-alone mode

The recorder can operate for up to three days in the stand-alone mode which means that you can perform several examinations without charging the battery and replacing the memory card.

Wireless interface for data transfer

The wireless interface allows for real-time data monitoring and analysis without removing the memory card from the device and copying the recorded data to PC.

American Academy of Sleep Medicine (https://aasm.org/)

Delivery Set

The delivery set can differ from country to country. Request the actual delivery set for your country from your local representative.

Neuron-Spectrum-AM electronic unit1 pcs.
Neoprene belt (1150 mm)1 pcs.
Neoprene belt (1400 mm)1 pcs.
Set of chest belts1 pcs.
Harness (1100 mm)1 pcs.
Harness (2000 mm)1 pcs.
Cable for disposable electrode: button clip – touch-proof (red, 1 m)2 pcs.
Cable for disposable electrode: button clip – touch-proof (black, 1 m)2 pcs.
AS-8/A-10 airflow sensor (adult)1 pcs.
AS-8/P-10 airflow sensor (pediatric)1 pcs.
SS-1-08 snoring sensor (0.8 m)1 pcs.
Set of IES-1-05 inductive thoracic and abdominal respiratory effort sensor (0.8 m)1 pcs.
IES-1-05 electronic unit2 pcs.
1 pcs.
2 pcs.
2 pcs.
Reusable inductive belt2 pcs.
Technical manual «ES-1-05, IES-1-22 Inductive Thoracic and Abdominal Respiratory Effort Sensors»1 pcs.
Reusable finger sensor for SpO2 recording (adult)1 pcs.
Disposable finger sensor for SpO2 recording9 pcs.
Reusable finger sensor for SpO2 recording (pediatric)1 pcs.
Set of mounting bracket for disposable sensor1 pcs.
Disposable ECG electrode (D=26 mm, price for 1 pcs., comes in packs of 30 pcs.)30 pcs.
SDHC memory card, 16 Gb1 pcs.
Pouch for electronic unit1 pcs.
Wireless router1 pcs.
Battery charger GP1 pcs.
Adult nasal cannula1 pcs.
AAN10090 luer lock connector, male, 3.2 mm (adapter for nasal cannula)1 pcs.
Transpore medical tape1 pcs.
Package set1 pcs.
Technical Manual «Neuron-Spectrum-AM»1 pcs.
Warranty certificate1 pcs.
Technical manual «AS-7, AS-8, AS-9, AS-10 Airflow Sensors»1 pcs.
Technical manual «SS-1, SS-1-08 Snoring Sensors»1 pcs.
User manual «Neuron-Spectrum.NET»1 pcs.
Annex to user manual «Exam Manager»1 pcs.
