Poly-Spectrum-AM

Holter monitoring solution


  • 2 or 3-channel Holter monitoring solution
  • wireless connection with clinician’s workstation
  • one button acquisition start
  • fast data downloading to computer
  • software package for long-term ECG monitoring with PQ, QT, HRV, ABP, ST, HRT modules
Poly-Spectrum-AM

Description

Poly-Spectrum-AM is intended for Holter monitoring and allows for long-term 24- up to 72-hour ECG recording. The system also records respiratory rate, movement activity, body position, and detects pacemaker pulses that assures a more informative analysis and facilitates result interpretation. User comfort, the accuracy of automatic algorithms, a wide range of tools for result control and editing were our main target when designing the system. Poly-Spectrum-AM is intended for obtaining the most complete relative information and providing it in the summary form so that a specialist could easily find all significant events within the recording.

Customizable parameters and additional channels

The supplied software allows customizing test parameters including sampling rate that can be set at 250, 500 or 1000 Hz. The system can also record other data such as respiratory rate, movement activity, body position from other channels as well as detect pacemaker pulses simultaneously with ECG. This enhances system functionality for providing additional information about a patient.

State indication on the front panel

For user convenience, the recorder state is shown on its front panel by 3 indicators: “Operation” (the device is powered and operates properly), “Break” (indicates a break of one or several leads), “Low Battery” (battery replacement is required).

Wireless connection

The test can be controlled via Bluetooth using a computer. The patient can move freely while the specialist can check signal quality and monitor test progress in real time.

Audio comments

Using the headset, the patient can record audio comments during the test which provides additional possibilities of the patient diary.

On-the-fly battery replacement

The recorder features sound notification if the battery is discharged during the test. Replace the batteries on-the-fly and continue the recording.



One button acquisition start

The recording can be started without computer assistance, simply by pressing the button on the front panel.

2 or 3 ECG channel monitoring

The ECG can be obtained from 2 or 3 channels depending on the cable type.

Fast data downloading to computer

The data is downloaded to a computer for less than 2 minutes (at 250 Hz frequency for 24-hour recording) using USB interface and data compression without compromise on its quality.

Delivery Set

The delivery set can differ from country to country. Request the actual delivery set for your country from your local representative.

Poly-Spectrum-AM electronic unit1 pcs.
License for Poly-Spectrum-AM.NET software with Poly-Spectrum-AM.NET/PM additional software module1 pcs.
ECG cable (2-channel, for Poly-Spectrum-AM, China)1 pcs.
License for Poly-Spectrum-AM.NET software with Poly-Spectrum-AM.NET/QT additional software module1 pcs.
ECG cable (3-channel, for Poly-Spectrum-AM, China)1 pcs.
License for Poly-Spectrum-AM.NET software with Poly-Spectrum-AM.NET/EXT additional software module1 pcs.
Headset1 pcs.
License for Poly-Spectrum-AM.NET software with Poly-Spectrum-AM.NET/BM additional software module1 pcs.
Bag with the belt for shoulder1 pcs.
License for Poly-Spectrum-AM.NET software with Poly-Spectrum-AM.NET/EA additional software module1 pcs.
Battery charger GP1 pcs.
Bluetooth adapter1 pcs.
USB cable1 pcs.
Disposable ECG electrode (43х45 mm, price for 1 pcs., comes in packs of 50 pcs.)100 pcs.
Transpore medical tape1 pcs.
Software protection dongle1 pcs.
Warranty certificate1 pcs.
Package set1 pcs.
PS-AM insert box1 pcs.
Technical Manual «Poly-Spectrum-AM»1 pcs.
1 pcs.
User manual «Poly-Spectrum-АМ»1 pcs.
